Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine

Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine
Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine

Large Image :  Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine

Product Details:
Place of Origin: China
Brand Name: MRBEST
Certification: CE
Model Number: MR-ZY200
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wooden Packing
Delivery Time: 7-20 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500 sets per month

Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine

Description
Product Name: Electrolyte Injection And Vacuum Standing Machine Application: Electrolyte Filling & Vacuum Standing
Suitable Battery: Pouch Cell Battery Size: L20~240mm, W20~200mm, T0~25mm
Operation: PLC, Touch Screen Controlled Filling Accuracy: ±1%
Volume: 0.2ml~200ml Spitting Speed: 6ml/s Adjustable
Highlight:

CE Lithium Battery Vacuum Diffusion Chamber

,

Electrolyte Lithium Battery Vacuum Diffusion Chamber

,

Pouch Cell Battery Electrolyte Filling Machine

Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine 0

Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine 1



Lithium Battery Vacuum Diffusion Chamber And Electrolyte Filling Machine For Pouch Cell Assembly



Model: MR-ZY200



Applicable to the electrlyte filling and diffusion process of battery capacitors, after vacuuming and then electrolyte filling and vacuum diffusion. The electrolyte is more precision, absorption consistency, high reliability.



Features



• Electrolyte filling & standing 2 in 1 machine.

• It has extremely high measurement accuracy and repeatability.

• Multi-station with high efficiency, accurate precision, convenient and reliable operation.

• The inlet and outlet are connected by chemicial-resisitant hoses.

• Can be operated in glovebox or drying room.

• PLC, touch screen operation, flexiable parameters, high automation program.



Specifications



Model Electrolyte Injection and Vacuum Standing Machine MR-ZY200
Working Voltage AC110/220V optional
Application Pouch cell & Cylindrical cell
Battery Size

L20~240mm, Tab included,

W20~200mm, gas bag included,

T0~15mm

Working Station 7
Volume 0.2ml * 200mL filling, adjust according to filling pump
Filling Accuracy ±1%
Spitting Speed 6ml/s adjustable
Pipe Diameter Ф6mm
Standing Time Settable, max 9999min
Power 500W
Air Source 0.5~0.7MPa
Dimension L510 * W400 * H650mm
Weight 90kg
Material Key part is made of corrosion resistant 304SS, 316SS



Picture for Reference



Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine 2

Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine 3

Pouch Cell Assembly Machines



Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine 4
Cylindrical Cell Machine
Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine 5
Coin Cell Machines
Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine 6

MRBEST Factory Show

Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine 7

Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine 8

Pouch Cell Lithium Battery Vacuum Diffusion Chamber Electrolyte Filling Machine 9

Shenzhen Meirui Zhida Technology Co., Ltd


Manufacturer Vendor for Lithium Battery Equipment in Shenzhen China
MRBEST Engineers has over 20 years experience in Lithium-ion Battery Researching and Manufacturing!
MRBEST International Sales Team has over 10 years export experience
24*7 Online after-sale dept and quick response!
Provide complete solution for Battery & Material Research Equipment
MRBEST Factory with ISO Certificate and products are CE approved
