Benchtop Manual Electrode Stacking Machine for Pouch Cell Research
Model: MR-BDP200-A
Application: It’s used for stacking battery electrode and separator to multiple
layers to make battery core.
Product Introduction:
MR-BDP200-A is a semi-automatic stacking machine. It is an ideal tool for stacking multiple layers of positive & negative electrode and separator for pouch cell.
Main Features:
*Desktop, can put in a normal desktop;
*Machine calibration, easy operation and maintenance;
*The machine used batteries size range is large;
*Work with high efficiency, with digital display counter;
*Use the foot switch control cylinder action
Technical Specifications
| Model |
Benchtop Manual Electrode Stacking Machine MR-BDP200-A |
| Working Voltage |
AC110V-220V 50/60Hz |
| Power |
100W |
| Stacking mode |
Z fashion |
| Max separator feeding diameter |
φ250mm |
| Fixed Travel Distance |
300mm |
| Applicable electrode size |
Length:20～200mm
Width: 20～200mm
Thickness: within 18mm
Larger model for apply larger electrode is also available
|
| Travel Cycle |
1 - 9999 cycles |
| Suggested Air Pressure |
0.5 MPa (Air compressor is not included in the standard package.
Attention: If a gas cylinder is used instead of air compressor a two-stage pressure regulator must be installed on the gas cylinder to limit the pressure within the required working range for safe operation.
|
| Product Dimensions |
Stacking Platform: 650mm(L) x 400mm(W) x 700mm(H)
Control Box: 200mm(L) x 300mm(W) x 380mm(H)
|
|
Glove-box Compatible
|
Like in Lithium- sodium research, MR-BDP200-A can be used in the glovebox while order customized feed through to use in glove-box.
Compact design enables the operation inside the glove box with Ar atmosphere where Lithium Sulfur, Lithium Air, Lithium Solid State or Li-ion half cell will be assembled.
|
| Warranty |
One Year limited warranty with lifetime support |
| Weight |
30kg |
| Shipping Weight & Dimension |
37kg 500*500*600mm
31kg 400*450*240mm
|
Our Advantages
1. Steady and high quality ! -cause we are a manufacturer of Lithium Battery Equipment, and we only focus on one thing that is make professional Lithium ion Battery Equipment for customer around the world.
2. Friendly use! all MRBEST Battery Equipment with teach manual and support live teaching via media.
3. Reliable factory! My factory located in Shenzhen city of China, support factory visit and video factory visit .
4. 1 year warranty plus lifetime technical support.
5.All the parts use on machine, in stock forever.
6. Powerful technical support, NOT TRADE COMPANY! We are professional on Lithium Battery Equipment, the chief engineer team have
more than 20 years experience on lithium battery area, so we can easy do diagnose on machine if customer have question.
7. 100% PATIENCE to all customers! Our patience not only before consult order, also after-sale service, one by one .
