6KW Double Planetary Vacuum Mixer With 304 Stainless Steel Bucket

6KW Double Planetary Vacuum Mixer With 304 Stainless Steel Bucket
6KW Double Planetary Vacuum Mixer With 304 Stainless Steel Bucket

Large Image :  6KW Double Planetary Vacuum Mixer With 304 Stainless Steel Bucket

Product Details:
Place of Origin: China
Brand Name: MRBEST
Certification: CE
Model Number: MR-XJB-5L
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wooden Packing
Delivery Time: 7-20 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500 sets per month
Contact Now

6KW Double Planetary Vacuum Mixer With 304 Stainless Steel Bucket

Description
Name: Double Planetary Vacuum Mixer Effective Volume: 5L
Bucket Inner Diameter: 240mm Bucket Inner Depth: 180mm
Bucket Material: 304 Stainless Steel Working Voltage: AC 3×380V±5%, 50Hz
Total Power: 6KW Weight: 700KG
Highlight:

6KW Planetary Vacuum Mixer

,

Double Planetary Vacuum Mixer

Electrode Making Machine Double Planetary Vacuum Mixer for Supercapacitor Electrode Preparation



6KW Double Planetary Vacuum Mixer With 304 Stainless Steel Bucket 0



Model: MR-XJB - 5L



Product Introduction



MR-XJB-5L is used for mixing dispersion of various common battery powder and liquid to achieve uniform battery slurry, especially for the high viscosity technological process. The viscosity interval of applicable operating conditions is ≤1200000cP



Features:



• Form of jacket for temperature adjustment, the single-layer jacket for bucket wall is used for cooling or heating; and the single-layer jacket for bucket bottom is used for cooling or heating.

• Over temperature alarm system, safer and smarter.

• Operation failure stop: the frequency converter is self-provided with overload, overcurrent, overvoltage, leakage of electricity, short-phase protection

• Variable cross-section Non-prismatic mixing design can make slurry get better mixing effect.

• Touch screen, simple operation, high automation.



Main Parameters



Name Double Planetary Vacuum Mixer MR-XJB-5L
Effective Volume 5L







Lower bucket component

 Bucket inner diameter 240mm
Bucket inner depth 180mm
Bucket material 304 stainless steel
Form of discharge a G1/2’’ Triple-plate discharge ball valve equipped at the bottom of bucket



Mixing component

 Speed of mixing propeller 10~98rpm
Speed of planetary gearbox 5~50rpm
Pattern of mixing propeller Non-prismatic twist type, 90° spiral line
Quantity of mixing propeller 2 pieces
Distance between propellers 7±2mm
Distance between propeller and bucket wall 3mm
Distance between propeller and bucket bottom 3mm
Dispersed component 610~6100 rpm



Wiped-wall component

 Material of wiped-wall plate PTFE
Speed of wiping wall Consistent with the speed of planetary gearbox
Base and lifting component Lifting mode Electric lifting
Lifting travel ≤290mm





Upper bucket component

 Feeding hole of power powder DN50 equipped with one quick-release sight glass
Feeding hole of liquid One quick-release ISO 1/2
Spot-light One DN50
Vacuum connector One G 1/2’’ inner thread
Working voltage AC 3×380V±5%, 50Hz
Total power ＞4kw
Vacuum holding -0.0989Mpa, it is higher than -0.085Mpa after 24 hours holding, without leakage to bucket
Dimension L1463×W610×H1770mm
Weight 700kg
