Compact Gas Driven Battery Research Equipment Pneumatic Pouch Cell Cutting Machine

Compact Gas Driven Battery Research Equipment Pneumatic Pouch Cell Cutting Machine
Compact Gas Driven Battery Research Equipment Pneumatic Pouch Cell Cutting Machine

Large Image :  Compact Gas Driven Battery Research Equipment Pneumatic Pouch Cell Cutting Machine

Product Details:
Place of Origin: China
Brand Name: MRBEST
Certification: CE
Model Number: MR-QMQ85
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wooden Packing
Delivery Time: 7-20 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500 sets per month
Contact Now

Compact Gas Driven Battery Research Equipment Pneumatic Pouch Cell Cutting Machine

Description
Product Name: Pneumatic Cutting Machine For Pouch Cell Maximum Die Cutting Size: L85mmxW65mm
Punching Accuracy: ±0.1 Mm Vertical Burr: ≤12μm
Horizontal Burr: ≤20μm The Life Of The Die: Normal Use ≥30,000 Times
Air Cylinder: Max 1T  Die Cutting Stroke: 35mm
Highlight:

Gas Driven Battery Research Equipment

,

Pneumatic Battery Research Equipment

,

Pneumatic Pouch Cell Cutting Machine



Battery Research Equipment Pneumatic Cutting Machine for Pouch Cell Electrode Die Cutter



Compact Gas Driven Battery Research Equipment Pneumatic Pouch Cell Cutting Machine 0


Model: MR-QMQ85



MR-QMQ85 is a gas driven electrode die cutter for pouch cell cathode / anode cutting for pouch cell preparation. It is a necessary equipment for pouch cell research with very high cutting accuracy. Gas driven mode, electricity is not required. Compact size can be put inside glove box.



Main Features:





● Different size of cutting die can be optional and easy to replace.

● The cutting no burr, no coated material drop.

● 2 Start buttons, the die can only go down only when pressing the 2 buttons at the time to avoid hurting hands.

● Compact size can be put inside glove box.

● Long lifetime for the cutting die, >30000 times.





Specifications:



Model Pneumatic Cutting Machine for Pouch Cell MR-QMQ85
Driven mode Gas Driven
Cutting Die Size maximum L85 * W65mm, customized size is available
Cuting Accuracy ±0.1mm
Air Pressure

Max 1T, 0.7Mpa is suggested to cut battery electrode.

If it is used inside glove box, the gas same as glove box working gas.
Material Feeding Manual
Dimension L350 * W4230 * H300mm
Weight 40kg
