Pouch Cell Battery Research Equipment 200W Battery Electrode Stacking Machine

Battery Electrode Stacking Machine for Pouch Cell Research


Model: MR-BDP200-B

MR-BDP200-B is a semi-auto stacking machine which is used for stacking pouch cell anode, cathode and separator by "Z'' shape to make a pouch battery cell core. It is manually feeding material, electrode position correction and laminating process are completed automatically. It is high stacking efficiency, high accuracy of stacking. It is perfect for high efficiency stacking requirement, battery pilot production, factory trial-production, etc.

Main Features:

● Stacking qty can be pre-set.

● Stacking size is adjustable, maximum stacking size 150x150mm.

● Roll-type separator automatic servo constant tension control.

● Separator automatic photoelectric correction control.

● Manually feeding electrode, automatic position, mechanical arm pick up electrode, automatically stacking.

● More compact size makes it ideal for battery lab.

Technical Specifications
