Lithium Ion Battery Electrode Stacking Machine 200W Z Fashion Methode

Lithium Ion Battery Electrode Stacking Machine 200W Z Fashion Methode
Lithium Ion Battery Electrode Stacking Machine 200W Z Fashion Methode

Large Image :  Lithium Ion Battery Electrode Stacking Machine 200W Z Fashion Methode

Product Details:
Place of Origin: China
Brand Name: MRBEST
Certification: CE
Model Number: MR-BDP200-B
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wooden Packing
Delivery Time: 7-20 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500 sets per month

Lithium Ion Battery Electrode Stacking Machine 200W Z Fashion Methode

Description
Product Name: Lithium Ion Battery Electrode Stacking Machine Stacking Methode: Z Fashion
Stacking Electrode Size: 200mm X 150mm Max. 44mm X 44mm Min. Acceptable Separator Roll Size: 220mm O.D Max.
Max. Electrode Thickness: Piled Up Thickness < 12mm Aligning Accuracy: ±0.3mm For Stacked Electrodes
Power: 200W  Working Voltage: AC110V-220V 50/60Hz
Highlight:

Lithium Ion Battery Electrode Stacking Machine

,

Battery Electrode Stacking Machine 200W

Semi-auto Lithium Ion Battery Electrode Stacking Machine

Lithium Ion Battery Electrode Stacking Machine 200W Z Fashion Methode 0


Model: MR-BDP200-B



MR-DPB200 is a semi-auto stacking machine which is used for stacking pouch cell anode, cathode and separator by "Z'' shape to make a pouch battery cell core. It is manually feeding material, electrode position correction and laminating process are completed automatically. It is high stacking efficiency, high accuracy of stacking. It is perfect for high efficiency stacking requirement, battery pilot production, factory trial-production, etc.



Main Features:



● Stacking qty can be pre-set.

● Stacking size is adjustable, maximum stacking size 150x150mm.

● Roll-type separator automatic servo constant tension control.

● Separator automatic photoelectric correction control.

● Manually feeding electrode, automatic position, mechanical arm pick up electrode, automatically stacking.

● More compact size makes it ideal for battery lab.



Technical Specifications



Model

Lithium Ion Battery Electrode Stacking Machine

MR-DPB200

Working voltage AC110V/220V optional
Stacking size Min 40x40mm, Max 150x150mm, tab size is not covered. Customized size is available
Stacking thickness Max 30mm
Separator roll diameter φ250mm
Stacking layer Max 500 layers settable
Power consumption 1KW
Air pressure 0.5~0.7Mpa
Dimension L1000 * W780 * H1050mm
Weight 350kg



Our Advantages

1. Steady and high quality ! -cause we are a manufacturer of Lithium Battery Equipment, and we only focus on one thing that is make professional Lithium ion Battery Equipment for customer around the world.
2. Friendly use! all MRBEST Battery Equipment with teach manual and support live teaching via media.
3. Reliable factory! My factory located in Shenzhen city of China, support factory visit and video factory visit .
4. 1 year warranty plus lifetime technical support.
5.All the parts use on machine, in stock forever.
6. Powerful technical support, NOT TRADE COMPANY! We are professional on Lithium Battery Equipment, the chief engineer team have
more than 20 years experience on lithium battery area, so we can easy do diagnose on machine if customer have question.
7. 100% PATIENCE to all customers! Our patience not only before consult order, also after-sale service, one by one .
