CE Approved Prismatic Cell Assembly 10KW Lithium Ion Battery Electrode Coater

CE Approved Prismatic Cell Assembly 10KW Lithium Ion Battery Electrode Coater
CE Approved Prismatic Cell Assembly 10KW Lithium Ion Battery Electrode Coater

Large Image :  CE Approved Prismatic Cell Assembly 10KW Lithium Ion Battery Electrode Coater

Product Details:
Place of Origin: China
Brand Name: MRBEST
Certification: CE
Model Number: MR-SY300-3J
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wooden Packing
Delivery Time: 7-20 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500 sets per month
Contact Now

CE Approved Prismatic Cell Assembly 10KW Lithium Ion Battery Electrode Coater

Description
Name: Lithium-ion Battery Electrode Coater Coating Method: 3 Rollers Transfer Coating
Roller Width: 330mm (280mm Effective) Heating Temperature: RT~150℃
Drying Chamber Qty: 3 Sections (1m/section) Operating Substrate Thickness: Aluminum Foil(Al): 8-30um; Copper Foil(Cu): 8-30um
Coating Speed: ≤2m/min Suitable Slurry Viscosity: 2000-12000 Cps
Highlight:

CE Prismatic Cell Assembly

,

Prismatic Cell Assembly 10KW

,

Lithium Ion Battery Electrode Coater



Prismatic Cell Assembly Lithium-ion Battery Electrode Coater for Battery Slurry Coating

CE Approved Prismatic Cell Assembly 10KW Lithium Ion Battery Electrode Coater 0



Model: MR-SY300-3J



Lithium-ion Battery Electrode Coater has been developed mainly to coating process for lithium-ion secondary batteries electrode. This machine consists of Coating and Drying equipment to achieve the mass production process of electrode plates (cathode/anode materials) which is a key process in battery manufacturing field. It can provide coating styles to meet the demands of varieties , such as continuous coating, intermittent coating and simultaneous double-sided coating etc.



Features



* Each part of drying cabinet temperature can be controlled independently.

* This machine is the modular design, which is easier to operate.

* Continuous and intermittent coating can be changed freely.

* Tension control, it’s equipped with correction device.

* Lower & upper blowing heating oven with excellent drying.

* Comma coating blade metering, with precision adjustment mechanism to obtain high coating accuracy.

* Gap tracking system for double side coating.

* PLC control, high automation.



Technical Parameters



Name MRBEST Lithium-ion Battery Electrode Coater MR-SY300-3J
Coating method 3 rollers transfer coating
Coating mode Continuous & intermittent coating
Roller width 330mm
Effective coating width 280mm
Substrate thickness

Aluminium foil: 8~30μm

Copper foil: 8~30μm
Coating speed 0~0.5m/min, depending on the heating
Single side coating thickness after drying 20-200μm
Heating temperature RT~150℃
Heating oven 1m length ,customized length is available
Coating size accuracy L≤±1mm, W≤±0.5mm
Voltage 3PH 380V 50Hz
Total power 10KW
Compressed air 0.5~0.7Mpa
Dimension L6500*W1300*H1500mm
