Pouch Cell Vacuum Standing Box For Battery Electrolyte Diffusion
Model: MR-JZ300
The electrolyte diffusion & degassing chamber standing box is specifically designed for professional Li-ion Battery Research. It is mainly used for removing air from the electrolyte after it's been injected into the polymer Li-ion cell or after the formation for final sealing under a vacuumed condition.
Features
1. The vacuum remains stable. When holding, the vacuum is not much lower.
2. The product has a multi-stage cycle operation function. Helps the electrolyte to fuse more fully.
3. Through the perspective window, you can observe the changes in the cavity while working.
4. The upper cavity is driven by an air cylinder and guided by two linear guide sleeves, which can move up and down flexibly, and the guidance is accurate to ensure the product tightness requirements.
5. It can be applied to batteries of different specifications, and the adjustment is simple and convenient.
6. The main machine and the control box are separated design, so that the machine can work in the glove box or on the assembly line.
7. Easy operation, beautiful appearance, small size and light weight.
Specifications
| Model No. |
Pouch Cell Vacuum Standing Box MR-JZ300 |
| The cavity is made of aluminum alloy, which is corrosion resistant and has a firm structure |
| Standing time can be set to 0-9999S, adjustable, and pressure adjustable |
| Vacuum degree can reach above -95KPa (the buyer prepares the vacuum pump) |
| Good sealing performance, which can ensure that the air leakage in 1 minute does not exceed -1KPa |
| Power supply |
220V/50Hz; power: 100W |
| Compressed air source |
0.5～0.8Mpa; when used in the glove box, the cylinder power source must use the working gas 0.5～0.8Mpa used in the glove box |
| Volume in the cavity |
L320mm*W320mm*H175mm |
| Part of performing cavity action |
about L510mm*W355mm*H635mm |
| Control part |
about L465mm*W355mm*H345mm |
| Weight |
about 60K |
Our Advantages
1. Steady and high quality ! -cause we are a manufacturer of Lithium Battery Equipment, and we only focus on one thing that is make professional Lithium ion Battery Equipment for customer around the world.
2. Friendly use! all MRBEST Battery Equipment with teach manual and support live teaching via media.
3. Reliable factory! My factory located in Shenzhen city of China, support factory visit and video factory visit .
4. 1 year warranty plus lifetime technical support.
5.All the parts use on machine, in stock forever.
6. Powerful technical support, NOT TRADE COMPANY! We are professional on Lithium Battery Equipment, the chief engineer team have
more than 20 years experience on lithium battery area, so we can easy do diagnose on machine if customer have question.
7. 100% PATIENCE to all customers! Our patience not only before consult order, also after-sale service, one by one .
