2KW Lithium Battery Making Machine Pouch Cell Hot / Cold Press Machine

2KW Lithium Battery Making Machine Pouch Cell Hot / Cold Press Machine
2KW Lithium Battery Making Machine Pouch Cell Hot / Cold Press Machine

Large Image :  2KW Lithium Battery Making Machine Pouch Cell Hot / Cold Press Machine

Product Details:
Place of Origin: China
Brand Name: MRBEST
Certification: CE
Model Number: MR-RY200
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wooden Packing
Delivery Time: 7-20 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500 sets per month

2KW Lithium Battery Making Machine Pouch Cell Hot / Cold Press Machine

Description
Product Name: Pouch Cell Hot/Cold Press Machine Hot Press Area: 200*200mm
Heating TEM: RT-250℃, Adjustable TEM accuracy : ±2℃
Pressure: 1T Adjustable Air source: 0.5-0.8MPa
Power: 2KW  Voltage: AC110V / 220V Optional
Highlight:

2KW Lithium Battery Making Machine

,

Cold Press Lithium Battery Making Machine



Pouch Cell Hot/Cold Press Machine For Lithium Battery Core Formation



2KW Lithium Battery Making Machine Pouch Cell Hot / Cold Press Machine 0



Model: MR-RY200



MR-RY200 Pouch Cell Hot/Cold Press Machine is used for pouch cell cores hot flat pressing after stacking & winding to makes it easy to put into aluminium-laminated case and pouch cell formation. The heating pressing die size is L200 x W200mm. The upper and lower pressing plate temperature can be controlled independently and digital display by thermometer.



Features



● Upper and lower pressing die temperature can be controlled independently.

● Heating temperature adjustable from room temperature ~250℃ and digital display.

● Pressing pressure can be adjusted.

● Heating press time can be set.

● The heating pressing die is made from copper with good heat conduction.

● IR sensor and protection cover included for safety protection.



Technical Parameters



Model Pouch Cell Hot/Cold Press Machine MR-RY200
Working voltage AC110V / 220V optional
Pressing die size L200 * W200mm
Heating temperature Room temperature ~250℃ adjustable
Temperature accuracy ± 2℃
Heating power 1KW
Pressure Max 1T
Compressed air 0.5~0.7Mpa
Dimension L320 * W320 * H430mm
Weight 70kg



Our Advantages



1. Steady and high quality ! -cause we are a manufacturer of Lithium Battery Equipment, and we only focus on one thing that is make professional Lithium ion Battery Equipment for customer around the world.

2. Friendly use! all MRBEST Battery Equipment with teach manual and support live teaching via media.

3. Reliable factory! My factory located in Shenzhen city of China, support factory visit and video factory visit .

4. 1 year warranty plus lifetime technical support.

5.All the parts use on machine, in stock forever.

6. Powerful technical support, NOT TRADE COMPANY! We are professional on Lithium Battery Equipment, the chief engineer team have

more than 20 years experience on lithium battery area, so we can easy do diagnose on machine if customer have question.

7. 100% PATIENCE to all customers! Our patience not only before consult order, also after-sale service, one by one .
