MR-CP60 Manual Lithium Battery Making Machine Coin Cell Disc Cutter

MR-CP60 Manual Lithium Battery Making Machine Coin Cell Disc Cutter
MR-CP60 Manual Lithium Battery Making Machine Coin Cell Disc Cutter

Large Image :  MR-CP60 Manual Lithium Battery Making Machine Coin Cell Disc Cutter

Product Details:
Place of Origin: China
Brand Name: MRBEST
Certification: CE
Model Number: MR-CP60
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wooden Packing
Delivery Time: 7-20 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500 sets per month
Contact Now

MR-CP60 Manual Lithium Battery Making Machine Coin Cell Disc Cutter

Description
Name: Coin Cell Disc Cutter Cutting Die: Optional 3 - 24mm Customized Dies Are Available Upon Request
Structure: Adopt Aluminum Alloy Corrosion-resistant Material And Never Rusts. Max. Stroke Length: 25mm
Product Dimensions: 110mm(L) X 160mm(W) X 350mm(H) Net Weight: 6kg
Highlight:

Manual Lithium Battery Making Machine

,

Coin Cell Lithium Battery Making Machine

,

Manual Coin Cell Disc Cutter

Battery Making Machine Coin Cell Disc Cutter For Battery Lab Research



MR-CP60 Manual Lithium Battery Making Machine Coin Cell Disc Cutter 0



Model: MR-CP60



The Coin Cell Disc Cutter Machine is used for coin cell electrode punching with customized cutting die. It's operation is simple with light weight, The resulting discs can be used as electrode/separator discs of split test cell and coin cell for battery researches.



Cutting Die: 3 - 24mm Optional



Specifications:



Machine Model Coin Cell Disc Cutter MR-CP60
Operating Manual
Punching size

Optional 3 - 24mm customized dies are available upon request
Application Notes

For make CR2016, CR2025 or/and CR2032 coin cell batteries,

we will need at least three cutting dies:

A 15mm

B 16mm

C 19 mm (for separator to fully separate the electrodes)

For CR2450 coin cell:

20mm cutting die can be used for cutting electrode discs and the 23mm cutting die for separator disc.
Punching stroke 25mm
Punching thickness 0.005-0.5mm electrode and separator
Advantages

Simple operation

Light weight

Can both cut electrode and separator
Dimension 110*150*235mm
Weight About 6kg
Warranty One Year limited warranty with lifetime support



Our Advantages

1. Steady and high quality ! -cause we are a manufacturer of Lithium Battery Equipment, and we only focus on one thing that is make professional Lithium ion Battery Equipment for customer around the world.
2. Friendly use! all MRBEST Battery Equipment with teach manual and support live teaching via media.
3. Reliable factory! My factory located in Shenzhen city of China, support factory visit and video factory visit .
4. 1 year warranty plus lifetime technical support.
5.All the parts use on machine, in stock forever.
6. Powerful technical support, NOT TRADE COMPANY! We are professional on Lithium Battery Equipment, the chief engineer team have
more than 20 years experience on lithium battery area, so we can easy do diagnose on machine if customer have question.
7. 100% PATIENCE to all customers! Our patience not only before consult order, also after-sale service, one by one .
