Battery Making Machine China Transfer Film Coating Machine Suppliers
Model: MR-SY300-3J
MR-SY300-3J is a three-roller transfer coating equipment, which can be used for continuous coating and intermittent coating. It is convenient to apply for coating on various substrates, especially used for lithium-ion battery industry. This equipment is convenient for users to use, can meet the requirements of coating accuracy and consistency, and with excellent drying effect. It is the ideal choice for lithium-ion batteries, super capacitors, nickel batteries, etc.
Features
● The gluing roller is controlled by double servo rods, which can be adjusted to wind up according to different viscosity slurries.
● Continuous and intermittent coating can be freely switched.
● Substrate tension control, stabilized belt moving, equipped with correction device.
● Lower & upper heating oven with good drying effect.
● 3-roller transfer coating with larger coating width.
●Comma coating blade metering, with precision adjustment mechanism to obtain high coating accuracy.
● Adopting analog signal to control power heating, the heating system has high precision and long lifetime:
● PLC controller, touch screen operation, easy to operate.
● Solvent recovery processing device is optional.
Specifications
| Model |
Lithium Battery Electrode Three-Roll Transfer Coating Equipment
MR-SY300-3J
|
| Voltage |
AC380V |
| Power |
30KW |
| Coating method |
3 rollers transfer coating |
| Coating mode |
Continuous & intermittent coating |
| Roller width |
400mm |
| Effective coating width |
Within 350mm |
| Running substrate thickness |
Aluminium foil: 8~30μm
Copper foil: 8~30μm
|
| Coating speed |
About 1.5~3m/min |
| Coating accuracy |
±3μm |
| Single surface coating thickness range after drying |
20-200μm |
| Oven temperature |
Max150℃, temperaure difference in single-section oven ≤±2.5℃ |
| Oven length |
1.5m/pcs, total 3pcs oven |
| Coating size accuracy |
L≤±1mm, W≤±0.5mm |
| Compressed air |
Exhaust pressure is about 0.5Mpa after drying, filtering and regulation |
| Dimension |
L6500 * W1300 * H1800mm |
Our Advantages
1. Steady and high quality ! -cause we are a manufacturer of Lithium Battery Equipment, and we only focus on one thing that is make professional Lithium ion Battery Equipment for customer around the world.
2. Friendly use! all MRBEST Battery Equipment with teach manual and support live teaching via media.
3. Reliable factory! My factory located in Shenzhen city of China, support factory visit and video factory visit .
4. 1 year warranty plus lifetime technical support.
5.All the parts use on machine, in stock forever.
6. Powerful technical support, NOT TRADE COMPANY! We are professional on Lithium Battery Equipment, the chief engineer team have
more than 20 years experience on lithium battery area, so we can easy do diagnose on machine if customer have question.
7. 100% PATIENCE to all customers! Our patience not only before consult order, also after-sale service, one by one .
