Automatic Film Battery Coating Machine High Automation With Touch Screen CE Approved

Automatic Film Battery Coating Machine High Automation With Touch Screen CE Approved
Automatic Film Battery Coating Machine High Automation With Touch Screen CE Approved

Large Image :  Automatic Film Battery Coating Machine High Automation With Touch Screen CE Approved

Product Details:
Place of Origin: China
Brand Name: MRBEST
Certification: CE
Model Number: MR-TMH250
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wooden Packing
Delivery Time: 7-20 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500 sets per month
Contact Now

Automatic Film Battery Coating Machine High Automation With Touch Screen CE Approved

Description
Name: Automatic Film Coating Machine With Rapid Infrared Heating Cover Doctor Blade: 150mm Fixed Width As Standard, Other Size Optional
Coating Length: 250mm Maximum Max Heating Temperature: 120℃
Heating Type: Rapid Infrared Heating Cover Vacuum Pump: Built In Oil Free Vacuum Pump
Highlight:

Battery Coating Machine High Automation

,

Touch Screen Battery Coating Machine

,

CE Automatic Film Coating Machine

Automatic Film Coating Machine With Rapid Infrared Heating Cover



Automatic Film Battery Coating Machine High Automation With Touch Screen CE Approved 0



MR-TMH250 is an automatic film coater with a vacuum bed and a rapid heating cover that heats up to 120ºC. It is designed to produce films with consistent thickness using micrometer adjustable or fixed-thickness applicators. It has a stable driving system to promote a smooth coating with all types of materials. The pin holes on the bed can hold the substrate sheet on the bed via a vacuum. This is very helpful when performing coating on a thin substrate. It is an ideal tool for ceramic tape casting and Li-Ion battery electrode coating.



Features



• Touch screen operation, high automation.

• Vacuum aluminium chuck is designed for quick suction of substrate.

• Built-in vacuum pump is designed.

• Coating stroke length can be set.

• Heating temperature up to 120℃ adjustable, and it's digital display.



Technical Parameters



Name Automatic Film Coating Machine With Rapid Infrared Heating Cover
Powe
  • Heating Cover: 120 VAC 60Hz, 1850 W
  • Coater: 30W, 24VDC
Traverse Speed
  • 10 - 100 mm/sec variable [Without any load, the read traverse speed is around 90 mm/s when the speed is set as 100 mm/s. Therefore the real speed for coating should be calibrated by customer themslves by using a ruler and stop watch]
  • Accuracy: 10mm/sec
Stroke Length
  • 10 - 250 mm adjustable by using the Adjustable Position Switch
Max. Coating Dimensions 150mm(W) x 250mm(L)
Vacuum Be
  • A vacuum bed is made of aluminum alloy with a micro-size hole
  • Vacuum Chuck Dimensions: 365mm(L) x 200mm(W)
Rapid Heating Cover
  • 3 Electric Infrared Tubular heater Element is installed on the heating cover for rapid heating.
  • 1 thermocouple is installed for temperature reading.
  • Max Temperature: 120°C
  • Temperature accuracy: +/- 2°C
  • Heating Rate: approximately 1.2°C/s
Film Applicator One150 mm width Micrometer Adjustable Film Applicator is included, with adjustable thickness from 0.01 mm - 5 mm (Pic. 1)
Traverse Pusher is included for pushing the doctor blade to ensure constant speed coating
Note: Thinnest film can be achieved is > 10 microns
Vacuum Pump built-in one Oilless Vacuum Pump
Application Notes
  • You need a vacuum mixer to remove air bubbles from the slurry to make uniform coatings
  • You may need a Slurry Viscosity Tester to make coatings consistent
  • You may need a Vacuum Oven to dry the films and remove the binder after coating.
  • Rolling pressing is necessary to ensure good density and adhesion of electrode materials to the current collector substrate after coating.
Dimension L500 x W310 x H330mm
Weight 45kg



Our Advantages

1. Steady and high quality ! -cause we are a manufacturer of Lithium Battery Equipment, and we only focus on one thing that is make professional Lithium ion Battery Equipment for customer around the world.
2. Friendly use! all MRBEST Battery Equipment with teach manual and support live teaching via media.
3. Reliable factory! My factory located in Shenzhen city of China, support factory visit and video factory visit .
4. 1 year warranty plus lifetime technical support.
5.All the parts use on machine, in stock forever.
6. Powerful technical support, NOT TRADE COMPANY! We are professional on Lithium Battery Equipment, the chief engineer team have
more than 20 years experience on lithium battery area, so we can easy do diagnose on machine if customer have question.
7. 100% PATIENCE to all customers! Our patience not only before consult order, also after-sale service, one by one .
