Single Head Electric Injection Pump Battery Electrolyte Filling Machine
Model: MR-ZYB01
It is applied for precision measurement of high-end micro liquid medium in medicine, electrolyte, acid, solvent, diary products, glue, reagent and other industries. The high precision and compact design make it particularly perfect for battery electrolyte filling in battery lab research.
Features
• Suitable for high-end micro-precision liquid medium metering filling, adding, liquid injection/injecting, spraying and marking. Valveless design ensures stable flow.
• The pump core is made of special industrial ceramics (Zirconium Oxide ZrO2, Alumina Al2 O3), which has features of high-strength wear resistance, with anti-chemical reaction, the contact medium part is ceramic.
• The pump sleeve and parts are resistant to acid and alkali, suitable for metering in various harsh liquid environment.
• Positive displacement plunger structure, reciprocating rotation operation, adjust the stroke length and rotation period to change the flow rate.
• The system is with powerful functions, multi-capacity, multi-speed options, and can transform and transfer liquid in reverse.
Technical Parameter
| Name |
Single Head Battery Electrolyte Filling Machine
|
| Model |
MR-ZYB01 |
| Pump core material |
ZrO2, Al2O3 |
| Pump core performance |
Corrosion resistance, high temperature resistance, wear resistance, high hardness, low friction coefficient, long life |
| Pump core matching accuracy |
2 μm |
| Drive method |
Imported Servo Motor/Stepper Motor |
| Range of rotation |
1-1200rpm forward and reverse reversible |
| Speed control method |
pulse |
| Control display method |
Display control 4.3 inches touch screen man-machine interface dialogue operation |
| Programming software |
Display and Control Programmable Controller |
| Single stroke capacity range |
0 μL -10000 μL, Max10000 /1 stroke |
| Capacity calculation method |
Q total (total liquid volume) = Q stroke (stroke volume) × N stroke (stroke number) |
| Measurement accuracy |
Within 5‰ |
| Applicable medium temperature |
The temperature of the medium liquid is less than or equal to 250 ℃ (due to the different material selection, please specify when placing the order) |
| Catheter |
PE / Teflon / inlet inside diameter φ6, the outer diameter φ8 |
| Dispensing needle |
Φ2.5/Φ4.0/Φ6.0 (Needle and needle length optional) |
| Metering pump size |
L×W×H 201×125×147mm |
| Controller size |
L×W×H 295×215×157mm |
| Weight |
≈8kg including controller and metering pump |
| Applicable power supply |
AC 220V±10%, 50Hz/60Hz (standard) AC 110V±10%, 50Hz/60Hz (optional) |
| Working environment |
Temperature 0～40℃, relative humidity <80% |
| Protection level |
IP31 |
Our Advantages
1. Steady and high quality ! -cause we are a manufacturer of Lithium Battery Equipment, and we only focus on one thing that is make professional Lithium ion Battery Equipment for customer around the world.
2. Friendly use! all MRBEST Battery Equipment with teach manual and support live teaching via media.
3. Reliable factory! My factory located in Shenzhen city of China, support factory visit and video factory visit .
4. 1 year warranty plus lifetime technical support.
5.All the parts use on machine, in stock forever.
6. Powerful technical support, NOT TRADE COMPANY! We are professional on Lithium Battery Equipment, the chief engineer team have
more than 20 years experience on lithium battery area, so we can easy do diagnose on machine if customer have question.
7. 100% PATIENCE to all customers! Our patience not only before consult order, also after-sale service, one by one .
