Battery Electrode Rolling Press Machine Max Speed 6m/min Customizable

Large Image : Battery Electrode Rolling Press Machine Max Speed 6m/min Customizable

Product Details:

Place of Origin:	China
Brand Name:	MRBEST
Certification:	CE
Model Number:	MR-DG300
Document:	Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiable
Packaging Details:	Standard Export Wooden Packing
Delivery Time:	7-20 working days
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	500 sets per month

Contact Now

Battery Electrode Rolling Press Machine Max Speed 6m/min Customizable

Description

Product Name:	Battery Rolling Press Machine	Pressing Pressure:	Customizable
Pressing Speed:	Max 6m/min	Roller Diameter:	φ200mm
Roller Width:	330mm	Installation Size:	L2500 X W1500 X H1300mm
Highlight:	Electrode Rolling Press Machine , Battery Rolling Press Machine

Battery Rolling Press Machine For Press Battery Electrode

Model: MR-DG300

It is a hydraulic roller press machine, which is used for battery electrode rolling press process. Winding&unwinding device is optional.

Main Features:

• The pressing thickness is adjustable.

• It is designed with tension control.

• Winding & unwinding device with correction function.

• Touch screen control, high automation.

Specifications:

Name	Battery Rolling Press Machine For Press Battery Electrode MR-DG300
Pressing Pressure	Max 25T, customized pressure is available
Pressing Speed	Max 6m/min
Roller Diameter	φ200mm
Roller Material	9Cr3Mo
Roller surface hardness	＞HRC65
Roller Width	330mm
Pressing thickness	Max 2mm
Pressing accuracy	±1.5μm
Power supply	AC220V
Power	3KW
Compressed air	0.5~0.8Mpa
Installation size	L2500 x W1500 x H1300mm ( Roll press machine + winding & unwinding device )
Weight	≈ 600kg

Tag:

Battery Sealing Machine,

Lithium Battery Mixing Machine,

Battery Rolling Press Machine
