Lab Manual Coin Cell Machine Vertical Battery Electrode Rolling Press Machine

Large Image : Lab Manual Coin Cell Machine Vertical Battery Electrode Rolling Press Machine

Product Details:

Place of Origin:	China
Brand Name:	MRBEST
Certification:	CE
Model Number:	MR-DG100L
Document:	Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiable
Packaging Details:	Standard Export Wooden Packing
Delivery Time:	7-20 working days
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	500 sets per month

Contact Now

Lab Manual Coin Cell Machine Vertical Battery Electrode Rolling Press Machine

Description

Product Name:	Electric Roller Press Machine	Roller Diameter:	90mm
Roller Width:	100mm Other Width Available	Pressing Thickness:	0~2mm Adjustable
Feeding Speed:	Max 10mm/s Adjustable	Working Voltage:	AC110/220V Optional Upon Request
Power:	120W	Rolling Press Accuracy:	≤±0.005
Highlight:	Manual Coin Cell Machine , Lab Coin Cell Machine

Battery Making Machine Lab Manual Vertical Rolling Press Calendering Machine For Battery Electrode

Model: MR-DG100L

MR-DG100L Lab Roll Press Machine is a compact precision electric rolling press machine. It has dual rollers of 96 mm dia. x 100mm width and dual grade micrometer. This lab roll press machine is an ideal rolling press for adjusting thickness and increasing active material density of the electrode in Li-Ion batteries research after coating and drying.

Features:

1. Hard chrome plated on surface. Material HRC62.

2. Transparent protective plate is designed for safety operation.

3. Press gap is adjustable.

4. Rolling speed and press thickness is adjustable .

Application

Battery lab

Battery research

Lithium ion battery lab

Material research

Trial-production

Specifications

Model	3.93"Width (100mm) Lab Roll Press Machine MR-DG100L
Working Voltage	110V/ 220V AC Single Phase Selectable
Power	120W Total
Warranty	1 year limited manufacture warranty with lifetime support
Structure	1. Heavy duty steel frame, gears and handle 2. Φ96mm Dia. * 100mm width Rollers made from hardened tools steel (HRC >62) with Cr electroplated coating. 3. Dual micrometer for accurate thickness adjustment in the range 0-2mm Maximum 4. Equipped with a transparent protective plate, safe to use
Roller	Dimensions: 96mm Dia * 100mm W Material: Made from hardened tool steel (HRC >62) With Cr electroplated coating. With Finish >0.8
Rolling Press Accuracy	≤±0.005
Rolling Press Thickness	0-2mm adjusted with Dial Gauge
Rolling Press Width	100mm Optional for 150mm, 200mm, 250mm, 300mm & 400mm
Rolling Press Speed	0-40mm/s adjustable
Product Dimensions	385mm L 245mm W 355mm H ( 15” * 9.5” * 14”)
Weight	55KG
Application Notes	This roller is specially designed for battery R&D in terms of its advantages as affordable, compact and precise. 1. Must use ace tone to clean and dry rollers’ surfaces after each use to avoid rusting. 2. Coated Rust-proof oil if machine were to be unused for a long period time 3. The minimum thickness of the rolled sheet should depend on the physical property of the materials.
