Cylindrical Battery Equipment Pneumatic Cylindrical Battery Sealing Machine (Optional: 32650, 26650, 21700, 18650, etc)
Model: MR-QF650
MR-QF650 pneumatic cylindrical battery sealing machine is used for various size of cylinder cell and supercapacitor sealing process.(Optional Die 18650, 21700, 26650, 32650, 32700, etc.)
Configuration Die:
Standard 18650 cylindrical battery sealing die 1 set of 2 times sealing
(optional other cylindrical battery sealing dia).
Features:
* Pure pneumatic operation, no need to use electricity, easy to use;
* Two-station sealing, better sealing effect;
*Precise mold design ensures accurate and reliable sealing and solid steel structure design, stable and safe to use.
* Beautiful appearance, easy maintenance, small size, convenient operation.
* Can choose Compressed air or inert gas cylinders. The external exhaust of compressed air can prevent the atmosphere of the glove box from being damaged.
Specifications
| Model |
Pneumatic Cylindrical Battery Sealing Machine
MR-QF650
|
| Air Source |
0.6 to 0.8 MPa argon, nitrogen gas cylinder, or compressed air
(it is not recommended to use compressed air in the glove box)
|
| Exhaust design |
Specially designed exhaust port, can be externally connected by KF40 and other devices |
| Gas consumption |
one seal consumes about 480ml |
| Sealing pressure |
manual control valve, maximum pressure 1MPa, recommended pressure 0.7MPa |
| Sealing stroke |
30mm |
| Sealing dia |
standard 18650 series packaging dia, optional or additional specifications |
| Installation size |
L290mm*W205mm*H330mm |
| Weight approx. |
27Kg |
| Structural material |
high-strength chrome steel, the surface will not rust after environmental protection plating and spraying. |
| Compliance |
CE Certified |
| Warranty |
One year limited with lifetime support
Rusting and damage due to improper storage condition or maintenance are not covered by warranty
|
Our Advantages
1. Steady and high quality ! -cause we are a manufacturer of Lithium Battery Equipment, and we only focus on one thing that is make professional Lithium ion Battery Equipment for customer around the world.
2. Friendly use! all MRBEST Battery Equipment with teach manual and support live teaching via media.
3. Reliable factory! My factory located in Shenzhen city of China, support factory visit and video factory visit .
4. 1 year warranty plus lifetime technical support.
5.All the parts use on machine, in stock forever.
6. Powerful technical support, NOT TRADE COMPANY! We are professional on Lithium Battery Equipment, the chief engineer team have
more than 20 years experience on lithium battery area, so we can easy do diagnose on machine if customer have question.
7. 100% PATIENCE to all customers! Our patience not only before consult order, also after-sale service, one by one .
